ATW heat pump Atlantic Alfea Extensa A.I. 6, 6,0 kW
- Integrated Class A circulation pump;
- Effective operating range from -20 °C to +35 °C at outdoor temperature;
- Scroll compressor;
- Special patented counter-flow heat exchanger;
- Freon R32;
- High coefficient of performance (COP) - up to 4.26;
- V-RAM variable frequency drive;
- Single-phase power supply connection (230 V only);
- Quiet outdoor part 41 dB;
- Integrated cooling function;
- Possibility to add an internal temperature sensor;
- Possibility to add a second heating circuit module;
- Wi-Fi control via smartphone. With Cozytouch accessory;
- The heat pump comes with a 2-year warranty and the compressor with a 3-year warranty.
- Heating capacity +7 °C / +35 °C - Floor heating: 6kW
- Back-up heating: 3+3kW
- Pipe connection diameter (gas-liquid): 1/2″" - 1/4″.
Manufacturer: France
ADDITIONAL OPTIONS:
Wi-Fi module Bridge Cozytouch - 167,40€
Relay for activation of additional heater 3kW - 37,20€
Wi-Fi module Bridge Cozytouch and Navilink A59 INTER room thermostat (set) - 252.95€
Heat pump with the indoor unit can be wall-mounted and the outdoor unit installed outside, outdoors beneath eaves. These heat pumps are especially suitable for homes with underfloor heating (outlet temperature +55°C).
Features:
· with a coaxial counterflow heat exchanger that increases heat pump efficiency;
· no antifreeze fluid is required in the system;
· the heat exchanger remains clean even if the water contains impurities;
· efficient operation at outdoor temperatures from -20 to +35°C;
· the Class A circulation pump consumes less electricity;
· inverter-driven dual-rotor compressor;
· with a 16-litre expansion vessel.
· Atlantic heat pump control logic integrated into a Siemens controller;
· connectable to a single-phase power supply;
· R32 refrigerant;
· integrated 3 kW auxiliary heating element (you can order a relay that increases the heating element's output by three kilowatts);
· 3-year compressor warranty and 2-year heat pump warranty;
· heating output for underfloor heating at T=+7°C/+35°C: 4.5 kW, COP 4.52;
· energy class at T=+35°C: A++; at T=+55°C: A+.
Indoor unit specifications:
· dimensions (H x W x D): 847 x 448 x 482 mm;
· noise level: 39 dB(A);
· weight: 46 kg.
Outdoor unit specifications:
· dimensions (H x W x D): 620 x 790 x 400 mm;
· noise level: 41 dB(A);
· weight: 41 kg.
Atlantic Extensa A.I. heat pumps can be used to produce hot water and for space heating and cooling. Additional modules can be installed to expand the heat pump's functionality—these modules allow you to cool rooms, control two heating circuits, connect a water heater, remote control and Wi-Fi control consoles.
