Multifunctional heat storage tank Dražice NADO v2 (140L), with insulation

Categories: Dražice

The Dražice NADO v2 multi-purpose tank is a more budget-friendly solution for heating and hot water. For hot water production, it has a built-in 140L tank with an enamelled inner layer. The tank is equipped with one heat exchanger (1.4 m2) for the connection of additional heating equipment, such as a solar collector system. It is worth mentioning that this heat exchanger must not be used for hot water production - the internal reservoir is used for this purpose.

Main parameters (see below for extended technical data of the tank):

  • Capacities: 500L, 750L, 1000L;
  • Internal reservoir capacity: 140L;
  • Built-in heat exchanger size: 1.4 m2.

The tank can be purchased with Dražice Neodul 80mm insulation.

Dražice NADO tanks are covered by a 5-year warranty.

Energy efficiency class: B / C

Manufacturer: Czechia

Available for order
Model NADO 500 (140L)
Volume 500 l
Volume (internal hot water tank) 140 l
Max. pressure inside heat storage tank 0,3 MPa
Max. pressure inside heat exchanger 1 MPa
Max. pressure inside hot water heater 0,6 MPa
Max. temperature inside heat storage tank 90 °C
Max. temperature for technical water inside heat exchanger 110 °C
Max. temperature for technical water inside water heater 90 °C
Weight 158 kg



Model NADO 750 (140L)
Volume 750 l
Volume (internal hot water tank) 140 l
Max. pressure inside heat storage tank 0,3 MPa
Max. pressure inside heat exchanger 1 MPa
Max. pressure inside hot water heater 0,6 MPa
Max. temperature inside heat storage tank 90 °C
Max. temperature for technical water inside heat exchanger 110 °C
Max. temperature for technical water inside water heater 90 °C
Weight 179 kg



Model NADO 1000 (140L)
Volume 1000 l
Volume (internal hot water tank) 140 l
Max. pressure inside heat storage tank 0,3 MPa
Max. pressure inside heat exchanger 1 MPa
Max. pressure inside hot water heater 0,6 MPa
Max. temperature inside heat storage tank 90 °C
Max. temperature for technical water inside heat exchanger 110 °C
Max. temperature for technical water inside water heater 90 °C
Weight 207 kg
