The NADO v6 multi-purpose tank is equipped with a single heating heat exchanger, which allows additional heating sources (e.g. air-to-water heat pump or solar collector system) to be added. Hot water is produced by means of an integrated stainless steel heat exchanger - instantaneous hot water heater.  The tank can be purchased in different capacities, depending on the size of the boiler room and the size of the heating system.

Main characteristics (see below for full technical info):

• Volumes: 300L, 500L, 750L, 1000L;
• Diameter (with insulation): 670mm (300L), 760mm (500L), 910mm (750L), 1010mm (1000L);
• Heat exchanger dimensions: 1.6 m2 (300L and 500L), 2.2 m2 (750L), 3.3 m2 (1000L);
• Flow-through hot water heat exchanger dimensions: 4.5 m2 (300L), 6.25 m2 (500L), 8.5 m2 (750L), 10 m2 (1000L).

The multi-purpose tank is available with Dražice Neodul 80mm insulation (excluding the 300L model, which comes with insulation).

Dražice NADO multi-purpose tanks are covered by a 5-year warranty.

Energy efficiency class: C

Manufacturer: Czechia
